APLINK LCX Series High Resolution Inkjet Printer
The APLINK LCX Series High Resolution Inkjet Printer is an industrial coding system designed for high-contrast marking on porous secondary packaging. Commonly installed in factories, distribution centers, and logistics warehouses, it supports carton and case identification with stable print quality at line speeds up to 50 m/min. The LCX Series InkJet Printer operates with print heights from 17 mm to 72 mm and maintains a controlled print distance of up to 5 mm, making it suitable for GCC and wider Middle East industrial environments.
In UAE industrial zones such as Dubai and Sharjah, the LCX Series InkJet Printer integrates directly into warehouse dispatch lines and manufacturing output lanes. It supports print heights between 17 mm and 72 mm and operates at speeds reaching 50 m/min, allowing operators to maintain throughput without slowing packaging flow. The system supports vertical, horizontal, and tilted mounting positions up to 90°, giving flexibility during line layout planning.
The printer connects via Ethernet or USB and works with external encoders and sensors to synchronize print timing. Data can be sourced from ERP systems, enabling variable information such as batch numbers, barcodes, dates, and counters. The 5.7-inch touchscreen provides direct control, reducing reliance on external PCs and simplifying daily operation.
Technical Specifications
| Product Code | APLINK LCX |
| Technical features | |
| DESCRIPTION | High Resolution Inkjet Printer |
| POWER SUPPLY | External module INPUT 110v / 240v I 50-60Hz I 15W |
| MESURES | 618mm x 140mm x 223mm |
| Consumable | |
| INK | 100% Mineral oil free ink for porous surfaces |
| COLORS | Black, red, blue & yellow. Other colours under request. |
| INK BOTTLE | 500 ml / 1000 ml Ink Bottle |
| PRINTING SURFACE | All types of porous substrates |
| Printing module features | |
| HEIGHT | 17mm (0,67 in) printer 72 mm (2,76 in) printer |
| PRINTING SPEED | Up to 50 m/min (164 ft/min) |
| RESOLUTION (vertical / horizontal) | 180 dpi / up to 360 dpi |
| CAPACOTY (CPM) | Up to 2 prints per second |
| PRINTING DISTANCE (between printhead and surface) | Max 5 mm (0,2 in) |
| PRINTHEAD WORKING POSITION | Vertical, horizontal, tilted up to 90º |
| DISPLAY | 5.7” Colour Touch Screen (VERTICAL) (640x480px) |
| CONNECTIVITY | 1 USB 2.0, 1 Ethernet 10 / 100 / 1000 |
| LABEL DESIGN SOFTWARE | UBS Designer Lite and UBS Designer Pro |
| BARCODE | DUN14, EAN 8, EAN13, EAN 128, CODE 19, CODE 128, 2/5 INDUSTRIAL, 2/5 INTERLEAVED, DATAMATRIX, QR, etc… |
| DATA | Fixed or variable text, dates, counters, formulas, logos, images... Use Windows TM and Truetype Tm fonts |
| LANGUAGE | Supports symbology like Cyrillic, Japanese, Chinese, Korean, Hebrew, etc. |
| OPTIONS & ACCESORIES | External encoder kit, light signal beacon, RS232, stand. |
| Connections | ETHERNET, USB |
Key Features
- High-resolution piezoelectric printhead for porous carton surfaces
- Printing height range from 17 mm to 72 mm for case coding
- Line speed support up to 50 m/min on conveyor systems
- Vertical, horizontal, or angled printhead mounting up to 90°
- Mineral-oil-free ink with fast absorption on corrugated materials
- 5.7-inch color touchscreen for local control and monitoring
- Ethernet and USB connectivity for data and system integration
- Support for variable text, barcodes, dates, and serial counters
APLINK LCX Series High Resolution Inkjet Printer
Brochure | Quotation | Availability
Fill the form with valid details to receive the information.
Product Videos
Frequently Asked Questions
The APLINK LCX Series is designed for porous secondary packaging such as corrugated cartons, kraft boxes, and paper-based cases. In UAE warehouse and manufacturing operations, including facilities in Dubai and Sharjah, it is commonly used for outer case identification, shipping labels, and logistics markings where ink absorption and print durability are required.
The system uses encoder-based synchronization to match print timing with conveyor movement. At speeds up to 50 m/min, the printhead adjusts firing frequency based on real-time line speed. This setup is widely used in UAE distribution centers handling mixed carton sizes without compromising barcode readability or text alignment.
Yes, the printer can function independently using its integrated touchscreen interface. Operators can load, select, and modify print jobs directly on the unit. In GCC logistics environments, this reduces dependency on control room PCs and simplifies daily operation during shift changes or network downtime.
Routine maintenance mainly involves periodic printhead inspection and cleaning of the nozzle area to remove paper dust. The mineral-oil-free ink reduces residue buildup. In high-volume UAE warehouses, technicians usually perform quick visual checks and scheduled cleaning without stopping production for extended periods.
The LCX Series supports variable data input through Ethernet integration with ERP or warehouse management systems. Batch numbers, pallet IDs, and dates can be updated automatically per carton. This is commonly applied in UAE export-oriented operations serving Middle East and Africa distribution routes.
