Manufactured by Hyster-Yale Maximal Forklift (Zhejiang) Co., Ltd, this versatile forklift range is built for heavy-duty applications, offering various capacities and lift heights to suit diverse industrial needs.

4.5-Compact 12ton IC Forklift Catalogue | 1.5-Compact 4ton IC Forklift Catalogue

FEATURES & BENIFITS:

ATCOLIFT / Maximal Forklift Trucks are CE compliance certified and made as per the European Standards
“ISUZU 6BG1” DIESEL POWERED 6.5L ENGINE - Made in JAPAN
Our Trucks are built with powerful Isuzu 6.5 L Engine made in Japan which comes with the well proven Industry-best productivity and reliability. Also, this rugged and reliable industrial engine will enhance the power and torque requirements for the demanding applications
The Truck is well designed and built with Zhongnan / ZhongChai TCM Technology Transmission, Gear pump and multivalve from Shimadzu Japan and steering gear from Zhenjiang. Reputed brands and reliable parts are the heart & soul of our machines
HYDRAULIC SYESTEM COMPONENTS: Premium hydraulic hose, fittings and steel tubes are vital to operator safety and load handling. All hydraulic cylinders use premium seals eliminating leaks and pressure loss. Main lift cylinder has a lowering speed valve to avoid rapid decent should a pressure lose occur in the lifting system. Fully adjustable steering wheel allows multiple operator sizes and added comfort. Power steering provides precise control and easy maneuverability in confined spaces reducing operator fatigue and stress
The LCD display monitors the machine’s vital components and electrical systems including travel speed and operating time. The monitor with integrated diagnostic system provides easy service and lower maintenance costs. The advanced design wiring harness uses waterproof connectors and an enclosed multiunit fuse module for improved circuit security and reliability
Latest technology LPG and Diesel engines have EPA tier 3 and EU stage IIIA rated engines certified to meet/exceed CARB emissions. These High-performance engines use less fuel per operating hour and eliminate harmful emissions in the workplace
MAXIMAL lift trucks are designed for the operator to be more productive and require less downtime for maintenance
MAXIMAL value-added lift trucks have earned a reputation for being tough, reliable and agile to handle more product with less operator effort in virtually every application
MAXIMAL Easy and low-cost maintenance helps to reduce the TCO (Total cost of ownership)

Product Code	FD25T-M3	FD30T-M3	FD35T-M3	FD40T-M3	FD50T-M	FD70T-M
Capacity	2.5ton 3m mast	3ton 3m mast	3.5ton 3m mast	4ton 3m mast	5ton 3m mast	7ton 3m mast
Other Options	2.5ton 3.3m-6.5m mast	3ton 3.3m-6.0m mast	3.5ton 3.3m-6.0m mast	4ton 3.3m-6.0m mast	5ton 3.5m-6.5m mast	7ton 3.5m-6.5m mast
Rated Capacity (kg)	2500	3000	3500	4000	5000	7000
Load Centre (mm)	500	500	500	500	600	600
Turning Radius (mm)	2330	2450	2510	2715	3250	3370
Wheelbase (mm)	1600	1700	1700	1900	2250	2250
Speed	Travel (Unladen): 19 km/h	Travel (Unladen): 18.5 km/h	Travel (Unladen): 18.5 km/h	Travel (Unladen): 18 km/h	Travel (Laden/Unladen): 24/26 (WJ3)	Travel (Laden/Unladen): 24/26 (WJ3)
	Lifting (Laden): 510 mm/s	Lifting (Laden): 410 mm/s	Lifting (Laden): 330 mm/s	Lifting (Laden): 430 mm/s	Lifting (Laden/Unladen): 400/420 (WJ3) mm/s	Lifting (Laden/Unladen): 380/400 (WJ3) mm/s
	Lowering (Laden): 450 mm/s	Lowering (Laden): 430 mm/s	Lowering (Laden): 430 mm/s	Lowering (Laden): 425 mm/s	Lowering (Laden): 500 mm/s	Lowering (Laden): 500 mm/s
Max. Gradeability (Laden) (%)	20	15	15	15	15	17
Self Weight (kg)	3640	4280	4700	5050	8080	9450
