Motorized Spiral Conveyor
A Motorized Spiral Conveyor is a vertical material handling system designed to move cartons, totes, and parcels between different levels within warehouses and production facilities. Common across UAE and wider GCC logistics operations, it supports continuous floor-to-floor transfer while reducing manual handling. The system manages loads up to 75 kg per unit and accommodates parcel sizes up to 600 x 600 x 600 mm, making it suitable for distribution centers, e-commerce hubs, and packaging lines across the Middle East and Africa.=---
The conveyor supports bi-directional movement and allows multiple infeed and discharge points, enabling flexible routing of goods across different processing stages. With throughput reaching around 1500 units per hour and operating speeds between 10–20 meters per minute, it handles consistent material flow without interruption. The structure can reach heights up to 25 meters, making it practical for multi-level warehouse configurations. Its single-drive mechanism simplifies installation and reduces operational complexity, while the low-friction chain system ensures stable handling across varying load types.
Technical Specifications
| MOTORIZED SPIRAL CONVEYOR | |
|---|---|
| Min. Parcel Size | 100 x 100 x 10 MM |
| Max. Parcel Size | 600 x 600 x 600 MM |
| Parcel Type NA | Box, Non-Box & Postal Package |
| Max. Speed | 20 MPM |
| Max. Unit Load | 75 KG |
| Pitch | 1500 MM |
| Belt Width | 900 MM |
| Power Supply NA | 440 VAC, 50 Hz, 3 -Ø, 1.5 kW |
| Motor | Single Motor |
| Noise Level | < 75 DB |
| Traction | Upto 9 Mtrs |
| Max. Heigh | Upto 25 Mtrs |
Key Features
- Vertical transport system designed for continuous multi-level material flow
- Supports boxes, totes, bags, and mixed parcel types
- Multi infeed and multi discharge configuration for flexible routing
- Compact footprint suitable for space-constrained warehouse layouts
- Single motor drive system for simplified mechanical setup
- Operating speed range up to 20 meters per minute
- Handles unit loads up to 75 kg with stable traction
- Maximum conveyor height up to 25 meters for multi-floor operations
- Low friction chain design for reduced wear and smoother movement
- Continuous operation capability with minimal intervention requirements
Motorized Spiral Conveyor
Brochure | Quotation | Availability
Fill the form with valid details to receive the information.
Product Videos
Frequently Asked Questions
In facilities across Dubai and Abu Dhabi, it connects inbound, storage, and dispatch levels without manual transfer. It links horizontal conveyors across floors, allowing continuous product flow. This is particularly useful in e-commerce and distribution hubs where vertical movement is frequent and space utilization is critical within GCC warehouse layouts.
The system is suitable for cartons, totes, bags, and mixed parcel formats. It supports unit loads up to 75 kg and accommodates varying sizes without needing changeovers. This flexibility is useful in UAE logistics operations where product dimensions vary across FMCG, retail, and courier handling environments.
Under standard operating conditions, throughput can reach around 1500 units per hour, depending on product size and spacing. In high-volume facilities, consistent flow is maintained by synchronizing feed conveyors, ensuring that upstream and downstream processes operate without bottlenecks.
The spiral unit is typically positioned between horizontal conveyor sections, acting as a vertical transfer point. It supports multiple infeed and discharge points, allowing integration into sorting, packing, or dispatch lines. This setup is common in UAE distribution centers handling continuous material movement.
Routine checks include inspection of chain tension, drive components, and belt condition. Lubrication and alignment verification are performed periodically. The single motor design reduces the number of service points, making it manageable for maintenance teams in large warehouse environments.
The system can operate in typical Middle East industrial conditions, including heat and dust, when proper enclosures and maintenance schedules are followed. Material selection and periodic cleaning help maintain consistent performance in UAE and regional warehouse facilities.
