Weighbridge
Weighbridge is a heavy-duty industrial weighing system used to measure the weight of trucks and large vehicles in logistics yards, factories, and infrastructure projects across the UAE and GCC region. It supports accurate load verification during inbound and outbound vehicle movement. With capacity options ranging from 40 tons to 120 tons and platform sizes up to 18 x 3 meters, it is suitable for high-load applications requiring consistent and repeatable measurement.
The structure is built using modular steel platforms with U-shaped beams to distribute stress evenly and maintain structural stability. Platform sizes range from 6 x 3 meters up to 18 x 3 meters, supporting vehicle capacities between 40 tons and 120 tons. The system uses multiple double-ended shear beam load cells for load distribution and accurate measurement, typically with accuracy levels around 10 to 20 kg, depending on configuration.
The load cells are hermetically sealed and designed for resistance to moisture, dust, and corrosion, making them suitable for UAE outdoor conditions. The system integrates with digital indicators and software for data recording, vehicle tracking, and reporting. It supports continuous operation in high-traffic environments while maintaining measurement consistency and durability.
Technical Specifications
| Product code | AWB6340T | AWB9350T | AWB12360T | AWB18380T | AWB183120T |
| Capacity (T) | 40 | 50 | 60 | 80 | 120 |
| No. of load cells | 4 | 6 | 6 | 8 | 10 |
| Accuracy (kg) | 10 | 10 | 10 | 20 | 20 |
| Plarform size (m) | 6 x 3 | 9 x 3 | 12 x 3 | 18 x 3 | 18 x 3 |
Key Features
- Capacity range from 40T to 120T for heavy vehicle weighing
- Platform sizes from 6 x 3 m to 18 x 3 m for varied vehicle lengths
- Modular steel structure for easier transport and installation
- U-shaped beam design for uniform stress distribution
- Double-ended shear beam load cells for accurate measurement
- OIML-approved load cells with high reliability
- Hermetically sealed load cells for moisture and dust protection
- Waterproof junction box for stable signal transmission
- Digital indicator with data management capability
- Suitable for outdoor and high-traffic industrial environments
Weighbridge
Brochure | Quotation | Availability
Fill the form with valid details to receive the information.
Frequently Asked Questions
In UAE operations, weighbridges are installed at entry and exit points to measure truck loads during material movement. In Dubai and Abu Dhabi, they are widely used in construction, logistics, and bulk handling sectors to verify inbound and outbound weights, ensuring accurate billing, stock tracking, and compliance with transport regulations.
Capacity selection depends on the type of vehicles and load patterns. Common configurations range from 40T to 120T with platform lengths up to 18 meters. In UAE industrial sites, longer platforms are preferred for articulated trucks, ensuring full vehicle coverage and stable weight measurement during operation.
Modern weighbridges connect to software systems for capturing vehicle data, timestamps, and weight records. This allows integration with ERP and inventory systems. In UAE logistics environments, this helps automate reporting, reduce manual entry errors, and maintain accurate transaction records for dispatch and receiving operations.
Weighbridges are designed for outdoor installation and can operate in high temperatures, dust, and humidity conditions typical of the GCC. Load cells are sealed and protected, while junction boxes prevent moisture ingress. This ensures reliable performance in both industrial yards and exposed outdoor environments.
Typical weighbridge systems provide accuracy within 10 to 20 kg depending on configuration and load distribution. This level of accuracy is suitable for bulk material handling and transport verification. Regular calibration and proper vehicle positioning help maintain consistent results in UAE applications.
Maintenance includes periodic calibration, inspection of load cells and cables, and cleaning of the platform area to avoid debris buildup. In UAE facilities, routine checks ensure stable performance, while preventive maintenance helps avoid downtime in high-traffic industrial operations.
